LM Port Cablelok

Oval Cablelok

Article-Nr.: 857-50209

  • Cable range coverage from 12.5mm to 15.0mm
  • Dual outlet for loop through applications
  • Seals to in excess of 6m head of water
  • Highly repeatable installation - the quality of the seal is not dependant on the skill of the engineer
  • Ideal for use in hazardous areas as no heat or gas is required for installation
  • Supplied in multiples of 1
  • Supplied with installation lubricant sachet
Find technical documents for the product
   Add to request

Technical details

Variant
Oval - LM
Description
HellermannTyton’s patented Cablelok mechanical seal enables fast safe cable installation, providing a highly repeatable and consistent seal between the cable and the closure port with excellent non-leak performance. Tested to in excess of 6m head of water, the Cablelok does not rely on the skill and experience of the engineer to achieve the required seal, whilst installation times are typically reduced by up to 90%.
Cable ∅ min
12.5 mm
Cable ∅ max
15.0 mm
Colour
Black (BK)
Port
LM
Port count
2
Total Port Count
2
Content
1 X CABLELOK-LM40C, 1 x Allen Key, 2 x Lubricating Wipe
Packaging Content SKU Unit
pcs.
Packaging 1 - Qty
1
Packaging 1 - Weight (kg)
0.16 kg
Packaging 1 - Type
bag
Packaging 1 - Height (m)
0.38 m
Packaging 1 - Length (m)
0.25 m
Local order number
857-50209
