  • lead-in_gfh20_gabocom.jpg

    speedpipe with resin injection systems into the building.

House lead-ins GFH

Hauseinführung GFH/MIS
  • House lead-in with injection system for boreholes in the most common wall types.
  • Professional sealing is carried out with the help of a resin injection.

Features:

  • Applicable in buildings without/with basements (underground access)
  • water impact classes according to DIN 18533:
    W1.1-E: Soil moisture and non-pressing water in floor slabs and walls in contact with the ground
    W1.2-E: Soil moisture and non-pressing water in floor slabs and walls in contact with the ground with drainage
    W 2.1-E: Moderate impact of pressing water ≤ 3 m immersion depth
  • Gas and water tightness:1 bar
  • Bore diameter: Ø 20 mm
  • Installation angle: to 45°
  • Auxiliary means: cartridge gun (available separately)



  • NameSuitability for speedpipe ground (mm)Art. No.
    GFH 20 2 × 7 - 10 PRO1 x 7 / 2 x 7 / 1 x 10 / 2 x 103578
    GFH 20 1 × 12 - 16 PRO1 x 12 / 1 x 14 / 1 x 163579
  • After entering your personal data, you will receive access data to our download module to the email address you provided. You can then download the required documents for this product. Please select the relevant documents above the form.
    Download descriptionCategoryLast update
    Flyer House-lead-ins20.04.2022
